OEM 110V 19 Inch Network Rack Mount No Break Online UPS 6~10KVA Manufacturers, Supplier

Model: Winwin series 6-10KR (1-1Phase)

The REO Winwin series rack-mounted 6K-10KVA UPS delivers uninterrupted power with 110V/115V/120V input/output via online double conversion technology. Designed for servers and critical systems, it provides complete protection against outages, surges, and voltage fluctuations while maintaining continuous operation. Featuring industrial-grade reliability, advanced safety mechanisms, and voltage stabilization, this high-performance UPS effectively safeguards sensitive electronics for both residential and commercial applications.

Send Inquiry

Product Description

Key Features

◈High-frequency online double conversion

◈Output power factor 1.0 with DSP control

◈Active PFC, input PF > 0.99

◈Battery-free startup capability

◈Wide input voltage range: 55V-145V

◈Generator-compatible design

◈Cold start capability

◈Optional Remote On/Off (ROO)

◈Auto-sensing 50Hz/60Hz frequency

◈Robust design with FR4 PCB and conformal coating

◈Ideal for highly sensitive devices (CVCF operation)

Specifications

Accept Deeply Customized Products
Model	6KRL	10KRL
Capacity	6KVA/6KW	10KVA/10KW
Phase	Single phase input single phase output
AC INPUT
Wiring	1 phase 3 wires (L/N+PE)
Voltage Range	Line-Neutral: 55~145VAC
Frequency Range	40Hz~70Hz
AC OUTPUT
Output Voltage	110/115/120/127VAC
Waveform	Pure sine wave
Overload Capability	10min@105%~125%; 60s@125%~150%; 0.5S@>150%
EFFICIENCY
Line / Battery Mode	Up to 92%
ECO Mode	97%
PHYSICAL
Dimension (WxDxH mm)	440x493x88 (2U)	440x532x176 (4U)
N.W (kg)	12.6	24.1
